Universal Exclusive Alu Set-Up System for 1/10 Off-Road

HUDY #108905

Set-up System for all 1/10 off-road cars: <b>Fits all 1/10 off-road electric cars.</b>, Set-up system is used for adjustment of:, • camber & camber rise, • caster, • front and rear toe, • steering throw symmetry

148,15 € s 20.00% DPH
Na sklade
Kúpiť lokálne
Otázka k produktu

Set-up System for all 1/10 off-road cars:
Fits all 1/10 off-road electric cars (with drive axle diameter of 4.8mm or 3/16").
For XRAY XB4 must be used also #108928 alu shim 5x11.8x8mm.
Please note that the set-up system stands do not fit on 5mm wheel axles such as Losi22. It is suggested to drill the hole in the stands up to size 5mm which will allow the set-up stands to fit the 5mm wheel axles.
This Set-up system will fit also 1/10 Short Course, 1/10 Truck and 1/10 Truggy but must be used with optional wider upsidea meassure plate #108840


Set-up system is used for adjustment of:
- camber & camber rise
- caster
- front and rear toe
- steering throw symmetry

Main Features:
- premium-quality exclusive set-up system for 1/10 off-road buggies with 4.7mm wheelaxle with both pin and hex drive wheel adapters
- super-precise measurement and setting of front/rear camber, toe, steering throw, caster
- includes handy set-up nuts for quick assembly/disassembly
- backlash-free, wobble-free mounting
- fully ball-bearing equipped set-up stands (12 high-precision ball-bearings)
- ultra-smooth, ultra-precise movement and operation
- CNC-machined, hardcoated high-grade aluminum set-up stands
- CNC-machined, tough acrylic plastic toe/steering plate
- precision engraving for instant, reliable readings
- delivered in handy foam packing for comfortable and safe storage and transport

Premium-quality exclusive set-up system for 1/10 off-road buggies with 4.7mm wheelaxle with both pin and hex drive wheel adapters. May be used for super-precise measurement and setting of front/rear camber, toe, steering throw, and caster. Backlash-free, wobble-free mounting of the fully ball-bearing equipped set-up stands (12 high-precision ball-bearings) ultimately gives ultra-smooth, ultra-precise movement and operation.

Set-up stands are CNC-machined, hardcoated high-grade aluminum; toe/steering plate is CNC-machined, tough acrylic plastic. All components feature precision engraving for instant, reliable readings. Includes handy set-up nuts for quick assembly/disassembly. Delivered in handy foam packing for comfortable and safe storage and transport.

Wheel Nuts are not included and are available as option
